技術參數(shù)： |
|
|
|
| 型號 |
34DT500 |
38DT250 |
M22 |
| 電源頻率 |
50Hz/60Hz |
50Hz/60Hz |
50Hz |
| 使用電壓范圍 |
120V~220V |
120V~220V |
120V~220V |
| 使用溫度范圍 |
-10℃~+125℃ |
-10℃~+125℃ |
-10℃~+125℃ |
| 輸入功率 |
≤1.0W |
≤1.0W |
≤1.0W |
| 輸出轉(zhuǎn)速 |
500/600 RPM |
250/300 RPM |
250/3RPM |
| 輸出力矩 |
0.6mN.m |
0.6mN.m |
2mN.m |
| 絕緣電阻 |
≥100MΩ |
≥100MΩ |
≥100MΩ |
| 絕緣強度 |
1500V/1min. |
1500V/1min. |
1500V/1min. |
| 絕緣等級 |
E |
E |
H |
| 溫升 |
≤60K |
≤60K |
≤60K |
| 轉(zhuǎn)向 |
CCW |
CW |
CW | |
